JTAG-Booster for Intel XScale PXA270
Program a Flash Device
Use: JTAG270 /P filename [optionlist]
The specified file is programmed into the flash memory. The flash status is polled
after each cell is programmed (cell = 8-, 16- or 32-bit, depending on current data bus
width). In the case of a programming error, the contents of the flash memory are
written to a file with the extension DMP.
For a complete verify after programming, use an additional command line with the
verify function. In most cases, this additional verify step is not needed.
Software normally detects the type of the flash device. When auto-detection fails,
you should use the /DEVICE= option together with /8BIT or /16BIT or /32BIT to set the
right flash device and configuration.
Options
/DEVICE=devicename
The flash device is detected automatically by switching to auto-select mode. In case
of trouble, select the flash device using this parameter to avoid auto-detection.
Combine this option with one of the following options that specify the data bus width
and the option /BYTE-MODE , if applicable.
/8BIT /16BIT /32BIT
Specifies the data bus width to the target flash device. You can speed up
auto-detection if you specify the correct data bus size. You need this option together
with the /DEVICE= option to explicitly specify a particular flash configuration.
/BYTE-MODE
If there is a flash device connected to the CPU, which has a byte mode pin (8 bit and
16/32 bit bus mode), you can force it to be used as 8 bit mode with the option
/BYTE-MODE . In most cases, this option will not be needed.
/CFI
To be prepared for future flash chips, the JTAG-Booster integrates support for flashes
that contain the CFI (Common Flash Interface) information structure. CFI support is
www.digi.com
103
